Cutting Table

The Cutting Table, also known as a sample table, CNC table, or knife cutter
INDUSTRY
* Construction * Packaging * Automotive * Shoes & Apparel * Gaskets & Seals * Household Products * Sports Equipment
MATERIAL
* Foam * Corrugated * Plastic Corrugated * Rubber * Vinyl * Textiles * Leather
ADVANTAGE
* Dual cutting heads to significantly boost production output
FEATURE
* Supports .DXF file format input * Safe and user-friendly operation * Flexible for various cutting needs

View machine in action

Honeycomb
Corrugated
Vinyl
Foam Material

Machine Specification



CT-12002400CT-12002400SCT-13002800SCT-13002800D
Max. material size (1)mm
Inch
2400 x 1200 x 100
94 x 47 x 4
2800 x 1300 x 100
110 x 51 x 4
2800 x 1300 x 100
110 x 51 x 4
2800 x 1300 x 100
110 x 51 x 4
Overall dimensionsmm
Inch
3200 x 1670 x 1800
126 x 66 x 71
3600 x 1870 x 1800
142 x 74 x 71
7966 x 1980 x 1830
314 x 78 x 72
7966 x 1980 x 1830
314 x 78 x 72
Weightkg
lbs.
2500
5500
2500
5500
3000
6600
3084
6800
Max. Cutting speed (2)mm/s
Inch/s
700
27.5
700
27.5
700
27.5
700
27.5
Working   pressuremm
Inch
0.45 - 0.7 mpa
65 - 100 psi
0.45 - 0.7 mpa
65 - 100 psi
0.45 - 0.7 mpa
65 - 100 psi
0.45 - 0.7 mpa
65 - 100 psi
No. of Cutting heads1112
Standard blade thicknessmm
Inch
1.5
0.0394
1.5
0.0394
1.5
0.0394
1.5
0.0394
Standard blade lengthmm
Inch
30 - 120
1.18 - 4.72
30 - 120
1.18 - 4.72
30 - 120
1.18 - 4.72
30 - 120
1.18 - 4.72
Compressed air requirement90 - 100 psi
Electrical requirements (3)480V, 3PH, 5Wires
AWG8, 50/60HZ
Electrical power capacity8KW8KW12KW12KW

View machine in action

Machine Specification
