INDUSTRIES
- Construction
- Packaging
- Automotive
- Shoes & Apparel
- Gaskets & Seals
- Household Products
- Sports Equipment
MATERIALS
- PE/PP/XPE/PU Foam
- Corrugated & Honeycomb
- Plastic Sheets
- Rubber
- Sponge
- Various Rigid Materials
ADVANTAGES
- Forklift loads pallet; the machine automatically feeds, transports, die-cuts, and unloads materials without manual effort
- Changeover in seconds
- PLC control with servo motor-driven accuracy
- Fully automatic operation with minimal labor
- Minimal to zero vibration impact on flooring
View machine in action
Machine Specification
| Equipment model | HP-250T5545RF | HP-350T6555RF | |
| Max. cutting width (1) | mm Inch | 1,400 55 | 1,650 65 |
| Max. cutting depth (2) | mm Inch | 1,150 45 | 1,400 55 |
| Overall dimensions w/ conveyor | mm Inch | 11,369 × 3,526 × 2,147 447(L) × 138(W) × 85(H) | 16,000 × 3,700 × 2,330 630(L) × 145(W) × 92(H) |
| Weight | kg lbs. | 12,000 26,400 | 27,000 59,000 |
| Machine tonnage | 250 tons | 350 tons | |
| Full cycle time (3) | 5-10 seconds | ||
| Compressed air requirement | 90-100 psi | ||
| Electrical requirements (4) | 480V, 3PH, 5Wires AWG6, 50/60HZ | ||
| Electrical power capacity | 40KW | 76KW | |
| (1) (2) Max. cutting width and depth are max. dimension of die board. (3) Material and tool size dependent. Measured with 2'' thick 1.7 PCF extruded PE, the time doesn't include loading or set up time. (4) This is the standard electricity configuration, can be customized for your machine. | |||
