UV-Curable - ROBIN AUTOMATION

Digital Printer - UV-curable Ink The Printer delivers high-quality, 4-color output with crisp clarity and precision. Designed for efficiency, it offers near-instant setup—taking only seconds. It meets the demanding visual standards of Lithobox printing without requiring additional printing plates.

Key Features

Key Benefits

No plate-making costs
Easy to operate
Compact footprint
Highly cost-effective for short and medium runs

Ink Categories

UV-Curable

Key Features

Direct-to-Substrate Printing
High-volume, single-pass production with 16+ print heads.
Scan-Based Printing
Precision printing for detailed graphics and short runs.

View machine in action

Standard Version

With Auto Feeder

With Slotter and Printer

Machine Specification

Equipment model		DP-100H8SU	DP-100H16DU	DP-100H8SUA
Max. sheet width (1)	mm Inch	2,500 100	2,500 100	2,500 100
Min. sheet size (2)	mm Inch	100(W) x 240(L) 4(W) x 9.5(L)	100(W) x 240(L) 4(W) x 9.5(L)	100(W) x 240(L) 4(W) x 9.5(L)
Overall dimensions w/ Standard config.	mm Inch	4,300 x 1,600 x 1,900 170(L) x 63(W) x 75(H)	4,300 x 1,600 x 1,900 170(L) x 63(W) x 75(H)	4,300 x 1,600 x 1,900 170(L) x 63(W) x 75(H)
Weight	kg lbs.	2,800 6,160	2,800 6,160	3,200 7,055
Max. speed	m/min ft/min	50 164	50 164	50 164
Set up time (3)		3-5 seconds
Compressed air requirement		90 - 100 psi
Electrical requirements (4)		480V, 3PH, 5Wires AWG8, 50/60HZ
Electrical power capacity		14KW	16KW	14KW
Auto Feeder		NA	NA	Yes
Applicable material		Cardboard and others
(1) (2) (3) Max. material and speed are material dependent. measured with 32 ECT C flute corrugated. (4) This is the standard electricity configuration, can be customized for your machine.
