INDUSTRIES
- Construction
- Packaging
- Automotive
- Shoes / Clothing
- Gaskets
- Household Products
- Sports
MATERIALS
- PE / EPE / XPE Foam
- Corrugated Board
- Plastic and Corrugated Sheets
- Rubber
- Vinyl
- Textiles
- Leather
ADVANTAGES
- Supports multi-layer material loading with automatic conveyor feeding system
- Quick changeover in seconds
- PLC-controlled and servo motor-driven
- Compatible with a wide range of materials
- Minimal to zero impact on floor vibration
View machine in action
Machine Specification
| Equipment model | HP-200T6235AI | ||
| Max. cutting width (1) | mm Inch | 1,600 62 | |
| Max. cutting depth (2) | mm Inch | 900 35 | |
| Overall dimensions | mm Inch | 6,600 × 3,250 × 2,310 260 × 128 × 91 | |
| Weight | kg lbs. | 15,200 33,440 | |
| Machine tonnage | 200 tons | ||
| Full cycle time (3) | 5-10 seconds | ||
| Compressed air requirement | 80-100 psi | ||
| Electrical requirements (4) | 480V, 3PH, 5Wires AWG6, 50/60 HZ | ||
| Electrical power capacity | 35KW | ||
| (1) (2) Max. cutting width and depth are max. dimension of die board. (3) Material and tool size dependent. Measured with 2'' thick 1.7 PCF extruded PE, the time doesn't include loading or set up time. (4) This is the standard electricity configuration, can be customized for your machine. | |||
