RoboFold is an intelligent, fully automated line that transforms die-cut flat sheets into finished cartons or cases and delivers them as bundled bales, packed boxes, or palletized loads. By combining pre-feeding, folding, gluing, forming, packing, and palletizing into one streamlined process, RoboFold eliminates manual handling while boosting speed, accuracy, and efficiency.
Designed with servo-driven control, touchscreen operation, and modular flexibility, RoboFold adapts to diverse production needs—whether folding and gluing simple cartons, creating complex cases, or integrating full end-of-line automation. With production speeds up to 400 m/min, RoboFold is built to meet the demands of high-volume manufacturing while ensuring consistency, safety, and reliability.
View machine in action
| Equipment model | RF-1100H3 | RF-1100H32 | |
| Applicable material | E/F/N flute | E/F/N flute | |
| Paper spec | gsm lbs | 200 - 800 135 - 540 | 200 - 800 135 - 540 |
| Max. sheet width | mm Inch | 1,100 43 | 1,100 43 |
Overall dimensions | mm Inch | 15,800 x 1,800 x 1,500 622(L) x 71(W) x 59(H) | 15,800 x 1,800 x 1,500 622(L) x 71(W) x 59(H) |
| Weight | kg lbs. | 10,000 22,000 | 10,000 22,000 |
| Max. speed | m/min ft/min | 400 1,312 | 400 1,312 |
| Set up time (4) | 10 - 30 seconds | 10 - 30 seconds | |
| Electrical requirements | 480V, 3PH, 5Wires AWG8, 50/60HZ | ||
| Electrical power capacity | 27kw | 27kw | |
| Applicable material | Up to double wall | Up to double wall | |
| No. of gluing head | 3 | 32 | |
| Auto Feeder | Yes | Yes | |
